Electric motor

Yaskawa/Delta/Huichuan and other international and domestic first-line brand motors are stable and reliable. 4.4KW large motor, faster running speed, greater acceleration, higher accuracy, longer life

System

Bus control system.Friendess system\Weihong system

Rail

Taiwan HIWIN high-speed silent guide rail

Rack

Taiwan apex high precision grinding rack

Laser

MAX\ raycus, etc

Cutting head

Raytools\wsx\ Boci Black Diamond \ Germany Prezt, etc

Water cooler

S&A\Hanli

Transom

Steel pretreatment beam

Sheet metal

Electrostatic spraying process, with high rust resistance, longer use time

Advantages

Stack welded bed

The welding structure of the bed is more reasonable, and the strength is higher, which can ensure that the bed is not deformed for 30 years, and the equipment is high precision

Steel beam

The material is hard, the vibration is small, it is not easy to produce deformation and can provide better dynamic performance and better mute effect

Distributed machine

The equipment is conducive to transportation and has a variety of adjustment schemes, which has more advantages for the use of equipment

Adaptive power

Suitable for 1.5-12kw fiber laser, stable and effective cutting (support pipe bevel processing)

Dust removal system

Remove dust from side half pack, efficient and clean, high dust removal efficiency

Fully automatic charging device

The charging device is an automatic centering clamping structure, and adopts the cable-stayed mechanical transfer mode to make the structure more stable and longer life

Processing format

350 square with the same model, 12 meters automatic feeding, automatic unloading, manual feeding for 13m full tube

High speed rotation

The maximum rotating speed of the chuck is 80 RPM, which can  achieve high-speed processing of all thin tube materials and increase the processing speed by 30%

Motion parameter

Operating speed

Maximum operating speed Y-axis 80m/min X axis 80m/min rotation 80 revolutions

Acceleration

1.5G

Cutting speed

0-60m/min

Mechanical positioning accuracy

0.03mm·m

Repeated positioning accuracy

0.05mm·m

Functional characteristics

Automatic obstacle avoidance

In case of obstacles in the cutting process, the cutting head automatically avoids, reducing the probability of cutting head damage

Automatic typesetting

Automatic arrangement of cutting workpieces, saving time and effort to reduce plate waste

High efficiency process library

The manufacturer provides an efficient process library to provide stable technical support for efficient cutting of the equipment, and the cutting speed is 10% higher than that of conventional equipment

Model Selection M

LKLY-M11060

LKLY-M11070

LKLY-M110120

LKLY-M22060

LKLY-M22070

LKLY-M220120

LKLY-M35060

LKLY-M35070

LKLY-M350120

LKLY-M550120

LKLY-M35060

LKLY-M35090

LKLY-M55060

LKLY-M55090

LKLY-M55012
